2026 CFORCE 520
2026 CFORCE 520 £7199
With its low weight and compact footprint, ease of maintenance, excellent durability, premium standard equipment and excellent price, the CFORCE 520 has become a very impressive mid-size ATV.
CFMOTO recommends that the rider should always wear a helmet, eye protection and other protective clothing.
The latest evolution of mighty CFORCE 520 now includes:
- Improved rider ergonomic
- Improved rider ergonomic
- New exterior design
- 25% tighter turning radius over previous model
- Lighter weight but stronger frame
- Overall noise and vibration reduction
- Heatshield improvement on lower leg area
- Higher air intake position
- Bigger fuel tank
- More storage space
- New dashboard
- Arched front A-Arms for increased ground clearance
Available Colours
Specification
Engine
- Engine Type: Single-cylinder,Liquid cooled,4-stroke,SOHC,4-Valve
- Displacement: 495 cc
- Maximum Power: 25.5kW/6750 rpm
- Maximum Torque: 39 N·m/5750 rpm
- Fuel Supply: BOSCH EFI
- Ignition: ECU
- Transmission: CVT
Chassis
- Drive: Switchable 2WD/4WD
- Suspension: Front/Rear: Double A-arm independent suspension
- Shock Absorber: Front/Rear: Spring pre-load adjustable, oil damped
- Rim: Front/Rear: 12″
Dimensions
- Length x Width x Height: 2186×1157×1210 mm
- Wheelbase: 1288 mm
- Minimum Ground Clearance: 249 mm
- Minimum Turning Diameter: 5.6±0.5 m
- Dry Weight: 344 kg
- Towing Capacity: 802 kg
- Fuel Capacity: 16.5 L
2-YEAR ATV WARRANTY
All new CFMOTO CFORCE all-terrain vehicles include an impressive 2-year warranty. The parts and labour warranty reflects the impressive build quality, reliability and faith that we have in our quad bikes, and gives our customers total peace of mind. If you’re looking for a new quad bike that you can depend on and will work just as hard as you do, the CFMOTO range won’t let you down. Terms and conditions apply, contact us for details.
